Portable, high-performance breathing air compressor in an extremely robust, sturdy powder-coated roll cage with foldable transport handles. With its diesel or petrol engine and its extremely robust roll cage, this compressor is built for the harshest professional operating conditions.
Technical data compressor unit: 270-320 lpm 3-stage, 380-450 4-stage, air displacement: 270-450 lpm. 16.2 – 27 m³, 9.53 – 15.9 cfm
maximum working pressure: 260 bar (380/450 lpm – 420 bar)
Type-tested and TÜV-approved final pressure safety valve, low-pressure oil pump with oil filter, oil capacity 2.6 liters
FT 160 three-stage breathing air dryer system, dryer capacity approx. 600 m³ at 20° C filter wall temperature, automatic final pressure shut-off,
Control and monitoring of the automatic condensate drain is only possible in combination with the optionally available electric start version with battery.
Control and monitoring by AIRSAVE ULTIMATE air quality monitoring,
Optionally HONDA GX 270 petrol engine 6.3 kW or YANMAR DIESEL ENGINE 6.8 kW. or 380-450 Honda GX 390 6.7 kW 8.3 hp or Lombardini Diesel 15LD500 8.8 kW 11 hp
2 filling hoses with bleedable safety filling connections DIN 200 or 300 bar, optionally with attached filling manifold with 6 direct or optional hose connections.
Accessories scope of delivery:
detailed operating manual, parts manual, compressor logbook, compressor filling log, declaration of conformity,
Certificates for safety valves, hoses, separators, dryer unit, air quality and leak test,
Filter dryer cartridges 1 x FT 160 H
Dimensions: LxWxH 135 x 55 x 74 cm, weight approx. 195-225 kg.

For further information see datasheet
